Limit values

Maximum capacity

1600 ct / 320 g

Readability

0.001 ct / 0.0001 g

Repeatability (at nominal load)

0.001 ct / 0.0001 g

Linearity deviation

0.001 ct / 0.0002 g

Sensitivity temperature drift

3 ppm/°C

Typical values

Repeatability (at nominal load)

0.0008 g

Minimum sample weight (acc. to USP)

0.21 g

Minimum sample weight (U=1 %, k=2)

0.014 g

Minimum sample weight OIML

0.01 g

Settling time

2 s

Internal adjustment

yes, FACT

Weighing technology

MonoBloc

Interfaces

2 ( COM1, COM2)

Balance dimensions (W x D x H)

193x290x266 mm

Weighing pan dimensions

ø 90 mm

Usable height of draft shield

165 mm

Weight of balance

3.7 kg

Weights for routin testing

Large Weight/Class OIML/ASTM

200 g / F2/4

Small Weight/Class OIML/ASTM

10 g F1/3
