APPLICATION

For high volume , around the-clock production

For the large jewellery manufacturer.

Spot heating in industrial plants

Computer rooms

Laboratories

Steam rooms

Pilot plants and automobile after-market industries

FEATURES:

Automatic water level regiltion system

Electronically controlled sensors constantly monitor the water level
Maintaining the optimum operating level.

Electronic steam release valves

Each valve (two standard, a third is optional is operated by foot control, freeing your hands to work. Solenoid actuated with a flow of adjustment.

Pressure control

Factory preset at 8 BAR (120 psi), the pressure control maintains a constant operating pressuree.

Light control

1

steam production ( i.e., heating element is working)

2

each tap ( steam release valve )

3

the automatic pump

4

pump chamber ( i.e., low water pressure)

Water level sight glass

Allows visual observation of the water during operation

Low water preesute cut off

When water flow drops below the minimum required by the pump, shuts down and the circuit goes into a standby mode. This protects the pump impeller when water pressure, the pump resumes filling.

Steam pressure gauge

Allows visual monitoring of the steam level.

Specifications

380 volt operating voltage

3 phase ( 12 amp draw for each phase)

230 volt, single phase to jump

8.5 KW Heating Element

5 Gallon/ 20 liter capacity

0.75 HP pump ; produces 107 PSI/ 7.5 BAR unassisted

Other combinations are available
